Horizontal Strapping With AC Motor Driven A-72HE

Product Description

Horizontal strapping system with indexing head. Designed to strap & secure on pallet load with either polypropylene or polyester. Provide pallet loads good protection during transport.

  • For PP & PET strap
  • Arch anti-bump device
  • Commercial PLC control
  • Index sealing head 250 or 400 mm stroke
  • Individual control box with HMI touch panel
  • Auto detect for strap failure, short feeding & empty strap band
  • Variety of conveyors
  • Arch with side press device
  • Dispenser adopts electromagnetic brake system
Horizontal Strapping With AC Motor Driven A-72HE
Arch Size (W x H) 1450 x 1400 (Customize)
Cycle Time 20 sec. / strap
Max. Tension (kgs) 75
Strap Width (mm) 9,12,15.5,19 (Specified)
Sealing Method Heating element
Sealing Position Side
Reel I.D. (mm) 203 or 406 (Specified)
Min. Conveyor Height (mm) 350
Power Supply 220/230/380/415/440V,50/60Hz, 3PH
Power Consumption (kw) 3.5
Compressed Air 5 ~ 6 bars for side press device
Layout Dimension (L x W x Hmm) (50%,100%,150%,200%) 4810 x 1736 x 4000 (50%,100%,150%,200%)
*Specification subject to change without notice
