Product Description

Since our inception in the year 1997, we have been engaged in manufacturing and supplying top grade Box Wrapping Machine. Known for its hassle free functioning, the providing machine is widely used for wrapping the carton boxes to prevent them from moisture and other impacts. Finding its wide demands in food & beverage, pharmaceutical and other industries, this machine is available in various technical specifications for our patrons. The offered Box Wrapping Machine is manufactured with the use of quality-approved components and latest techniques by our skilled technocrats.

Key Points of Box Wrapping Machine:

  • Available with the adjustable wrapping plates
  • Less maintenance
  • User friendly operation
  • Energy efficiency
Box Wrapping Machine
Product details
Capacity Upto 150 Cartons / Hour
Direction of Rotation Clockwise (When viewed from top)
Film Usage LLDPE Stretch-Wrap Film 250-500mm/ 12-40microns/ 76mm
Max. Pallet Weight Upto 100 Kg
Motors AC Motors with Gear Box
Power 1 HP 3 Phase 415 V 50 Hz AC.
Pre-Stretch Range Upto 300%
Product Dimensions 700mm x 700mm x 600mm (L x W x H)
Product to be Packed Corrugated Cartons / Tin Cans / Multiple Books etc
Spool Carriage 4 FRD/PE Stretch Carriage
Stretching System Bi-Directional Wrapping
Turn-Table MS Fabricated 900mm Diameter / Variable Speed
Turntable Diameter. 1500mm (1800mm)
