Belt Driven Tabletop With AC Motor A-85NAB

Product Description

A-85NAB is designed for various in-line applications. A-85NAB can work with different strap widths, provide wide tension range as well as high strapping speed with AC motor driven. Diversity of assist functions is all as standard equipped.

Features
  • Belt driven
  • Looping ejector
  • Short feeding sensor
  • Coil end eject system
  • Waist auto loading system
  • Conveyor speed adjustable
  • Upstream and downstream interlock
  • Run on 5,6,9,12,15 mm strap (specified)
  • PLC control with HMI touch screen panel
Options
  • Top press – P
  • Various arch sizes
  • Stainless steel housing
Belt Driven Tabletop With AC Motor A-85NAB
Specification
Speed (straps / min) 40
Strap Width (mm) 5,6,9,12,15 specified
Tension Range for 5,6mm 3~30kgs
Tension Range for 9,12,15mm 5~70kgs
Standard Arch (W x H mm) 850 x 500
Motor AC
Sealing Method Heating element
Table Height (mm) 805
Power Supply 110/220/230/240V, 50/60Hz, 1PH 220/230/380/415/440V,50/60Hz, 3PH
Power Consumption (kw) 1.2
Layout Dimension (L x W x Hmm) (50%,100%,150%,200%) 1230 x 580 x 1430 (50%,100%,150%,200%)
*Specification subject to change without notice
